MINGSHANG · XCMG

设备图库

18 张实拍图

挖掘机XCMG2021

徐工 XE490DK 48 吨履带式挖掘机

可咨询 · 二手设备

矿山强化底盘、康明斯 QSM11 发动机与双主泵液压系统，面向大土方、矿区装载与重载开挖。

公开产品详情说明

A used 2021 XCMG XE490DK crawler excavator with a 48,100 kg operating weight, Cummins QSM11 engine and heavy-duty mining-oriented undercarriage. This is used construction equipment. Before purchase, please confirm current availability, production year, PIN or serial number, actual operating hours, engine and hydraulic configuration, operating weight, installed work tools and attachments, emissions compliance for the destination market, inspection report, price, Incoterms and shipping details. Specifications are based on the supplied unit photos and manufacturer reference files and may vary by individual machine.

48.1 t

280 kW

3.1 m³

6.53 m

适用任务

矿山剥离、大型土方、采石场装载

WhatsApp +86 182 3297 8808

告诉我们目的国、工况与数量，我们会进一步核验实车车况、配置和运输方式。

TECHNICAL DATA

详细配置

图片与基础参数参考公开产品资料整理；库存、车况、工时与最终配置须以实车检测和成交文件为准。

ConditionUsed

Stock reference03390

Year of manufacture2021, unit nameplate

ManufacturerXCMG

ModelXE490DK

Equipment typeCrawler excavator

Operating weight48,100 kg

Bucket capacity2.3–3.1 m³; standard reference 3.1 m³

Engine manufacturer / modelCummins QSM11

Engine configuration6-cylinder, direct injection, turbocharged, air-to-air intercooled, water-cooled

Rated power / speed280 kW at 2,000 rpm

Maximum torque / speed1,898 N·m at 1,300 rpm

Engine displacement11 L

Main pumps2 piston pumps

Main pump rated flow2 × 360 L/min

Main relief pressure34.3 / 37 MPa

Travel system pressure34.3 MPa

Swing system pressure31 MPa

Pilot system pressure3.9 MPa

Travel speed, high / low5.4 / 3.2 km/h

Swing speed9.2 rpm

Gradeability35°

Ground pressure85 kPa

Bucket digging force339 kN

Arm digging force279 kN

Maximum drawbar pull338 kN

Fuel tank capacity725 L

Hydraulic tank capacity430 L

Engine oil capacity48 L

Overall dimensions (L × W × H)11,830 × 3,582 × 3,770 mm

Track length5,353 mm

Track shoe width600 mm

Track gauge2,750 mm

Minimum ground clearance519 mm

Tail swing radius3,800 mm

Maximum digging height9,480 mm

Maximum dumping height6,800 mm

Maximum digging depth6,530 mm

Maximum digging radius10,580 mm

Maximum ground-level digging radius10,340 mm

Standard boom / arm length6,670 / 2,400 mm

参数说明:图片与基础参数参考公开产品资料整理；库存、车况、工时与最终配置须以实车检测和成交文件为准。
